The drop arm optical turnstile is a combination of the security of a tripod or barrier turnstile and a fully optical turnstile. The lanes can have either single or double arms. When access is granted the arms drop into recesses in the cabinet. Once the arms drop out of the way, the turnstile functions as a fully optical turnstile.

Optical:

Optical turnstiles are an alternative to the traditional “arm”-style turnstile and are increasingly used in locations where a physical barrier is deemed unnecessary or unaesthetic. Optical turnstiles generally use an infrared beam to count patrons and recognize anyone attempting to enter a site without a valid entry pass.

Waist-high:

Waist-high turnstiles are often used in fairs, attractions, and arenas. The user inserts a ticket or pass into the slot, from which a barcode is read; if access is to be granted, a sensor determines the speed with which the user passes through, and sets the electric motor to turn the turnstile at the corresponding speed. Sometimes also referred to as “half-height” turnstiles, this fixed arm style has traditionally been the most popular type of turnstile. There are many variations of this style available, including one which is designed to be accompanied by a matching ticket box, and one with a ticket box built in. Some styles are designed to allow entry only after a payment (actual coins and tokens) are inserted, while others allow access after a valid barcode is electronically read.
